Pulley extenders for Huxley
by whosawhatsis
4
Downloads
10
Likes
0
Makes
These pulley extenders fix the alignment of the x-axis belt on on the Mini Mendel Huxley so that the clamping side is properly aligned, and (more importantly) so that the belt does not rub against the chassis on the opposite side.
I was going to modify the x-blunt-plate_1off and x-motor-end-clamp_1off parts for this function, then try to cut passable replacements out of the acrylic left over from my froglet, but when I opened the files I found that none of the existing holes were properly ali
I was going to modify the x-blunt-plate_1off and x-motor-end-clamp_1off parts for this function, then try to cut passable replacements out of the acrylic left over from my froglet, but when I opened the files I found that none of the existing holes were properly ali
